Compact efficiency for your pneumatic solution.
In the world of pneumatics, every detail counts - and every connection. With the KPV distribution bar, SFS-Fluidsysteme offers a smart, space-saving solution for applications in which individual control circuits need to be safely disconnected.
The KPV distribution bar replaces up to ten individual ball valves with a single compact module with just one pressure inlet - for maximum efficiency in minimum space.
Function and design
The KPV distribution bar serves as a combined distribution and shut-off unit. Each outlet is equipped with an integrated ball valve that can be easily opened or closed using a screwdriver. The position of the ball valve is clearly visible through the slot in the spindle - for maximum control in the tightest of spaces.
Advantages
- Compactness: Up to 80 % space saving compared to conventional solutions with several individual ball valves.
- Fewer connection points: Thanks to the block solution, the number of connections is drastically reduced - minimizing leakage risks and increasing operational safety.
- Highest quality - Made in Austria:
Housing: anodized aluminium
Ball & spindle: chrome-plated brass
Ball seals: PTFE
O-rings: NBR - Time-saving: The pre-assembled distribution bar enables significantly faster installation compared to connecting several ball valves individually.
With the KPV distribution bar, SFS-Fluidsysteme therefore offers a solution that not only impresses with its compact design, but also with its simple handling, reduced risk of leakage and durable components.
